ASTM269 En10216

Overview

Basic Info.

Certificate	ISO 9001 Ts16949
Application	Precision Application
Secondary or Not	Non-Secondary
Standard	ASTM A269, A312, A249, A554, A789, A790, A268
Delivery Condition	Ap, Ba, Cfa, Cfp
Steel Grade	304, 304L, 316, 316L
Transport Package	Bundles or Boxes
Specification	OD1-250mm
Origin	China
HS Code	7306610000

Product Description

Detailed Photos

Standards

Standard	Material Chemical Composition
	Grade	C	Si	Mn	P	S	Cr	Ni	Mo
ASTM A269 ASTM A312 ASTM A249 ASTM A554 GB/T 12770 ASTM A789 ASTM A790 ASTM A268	304	≤0.08	≤1.00	≤2.00	≤0.045	≤0.030	≤18.0-20.0	8.0-11
	304L	≤0.030	≤1.00	≤2.00	≤0.045	≤0.030	≤18.0-20.0	8.0-12
	SUS316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.030	16.0~18.0	10.0~14.0	2~3
	SUS316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.030	16.0~18.0	10.0~15.0	2~3

Delivery condition: AP, BA, CFA, CFP Other sizes and material available upon request OD: 1mm-250mm WT: 0.05mm- 50mm Tolerance: OD+/-0.05mm ID +/-0.05mm Other sizes, grades and special tolerance available upon request Advantage:Sophisticated bright annealing technology makes the tube good mechanical performance,the tube can be flared,flatten,bent freely.

Applications

A. Hydraulic circuits (HPL), pneumatic lines, and hydraulic suspension
B. Hydraulic cylinders (HPZ)
